Commercial Fire-Rated Steel-Faced Wood Core Door
  • Commercial Fire-Rated Steel-Faced Wood Core Door Commercial Fire-Rated Steel-Faced Wood Core Door
  • Commercial Fire-Rated Steel-Faced Wood Core Door Commercial Fire-Rated Steel-Faced Wood Core Door
  • Commercial Fire-Rated Steel-Faced Wood Core Door Commercial Fire-Rated Steel-Faced Wood Core Door

Commercial Fire-Rated Steel-Faced Wood Core Door

Mingjue factory specializes in Commercial Fire-Rated Steel-Faced Wood Core Door for shopping malls, suitable for atriums, shop partitions, evacuation routes, and stairwells. As mandatory 3C-certified fire safety equipment, these doors provide excellent fire resistance and thermal insulation, effectively blocking flames and smoke to ensure safe evacuation and property protection.

Send Inquiry

Product Description

As a leading China manufacturer, supplier, and factory, Mingjue specializes in the Commercial Fire-Rated Steel-Faced Wood Core Door, designed for modern shopping malls and commercial complexes. This product combines structural strength, certified fire resistance, and refined aesthetics, ensuring compliance with strict fire safety standards while enhancing interior design. The Commercial Fire-Rated Steel-Faced Wood Core Door plays a vital role in fire compartmentation, effectively delaying flame spread, heat transfer, and smoke infiltration to protect lives and assets.


Commercial Fire-Rated Steel-Faced Wood Core DoorCommercial Fire-Rated Steel-Faced Wood Core DoorCommercial Fire-Rated Steel-Faced Wood Core Door


What is Commercial Fire-Rated Steel-Faced Wood Core Door?

The Commercial Fire-Rated Steel-Faced Wood Core Door is a composite fire door integrating a steel frame with premium wood panels. It functions as a certified fire barrier within commercial buildings.


Functions

● Maintains structural integrity and insulation during fire exposure.

● Provides safe evacuation time by limiting fire and smoke spread.


Technical Specifications

The following are standard technical specifications, which can be customized and adjusted for bulk orders to meet the specific requirements of shopping mall projects. All parameters have undergone third-party testing and comply with relevant national standards and fire safety regulations:

Parameter Name Standard Specifications Customization Options Applicable Standards
Fire Rating Grade A (1.5 hours), Grade B (1.0 hour) Grade A (2.0–3.0 Hours) GB 12955-2008
Door Body Material 1.2mm Cold-Rolled Steel (Frame) + Pine Wood Panel 1.0–1.5mm Cold-Rolled Steel + Oak/Birch Wood Panels GB 17565-2022
Core Filling Material High-Density Fireproof Thermal Insulation Rock Wool (120 kg/m³) Fire-Resistant Thermal Insulation (Rock Wool), Fireproof Perlite GB/T 11835-2016
Door Body Thickness 70mm 60–90mm Fire Safety Codes + Shopping Mall Requirements
Opening Method Swing Type (Single Leaf / Double Leaf) Sliding, Double-Leaf (Master-Slave) Opening GB 17565-2022
Standard Dimensions 1000 × 2100mm, 1500 × 2100mm 900×2000mm – 2000×2400mm Standard Door Opening Dimensions for Shopping Malls
Surface Finish Eco-friendly Clear Varnish (Transparent / Matte) Matte Paint Finish, Antique/Distressed Styling, Carved Embellishments GB/T 18581-2021
Hardware Accessories Fire-Resistant Silent Hinges, Fire-Resistant Lock Exquisitely Carved Fireproof Lock, Smart Access Control Compatible, Concealed Hinges GA/T 73-2015


Core Advantages

1.Fire Protection Performance

● Certified fire ratings (up to 3 hours) ensure compliance with international and national standards.

● High-density mineral core enhances thermal insulation and fire resistance.

2.Strength Meets Aesthetics

● Steel structure ensures durability under heavy traffic conditions.

● Natural wood finishes deliver a premium visual experience suitable for upscale malls.

3.Comfort and Efficiency

● Excellent thermal insulation reduces energy loss from HVAC systems.

● Noise-reducing seals ensure a quiet and comfortable environment.


Applications

Commercial Spaces

● Shopping malls, retail stores, and commercial corridors.

● Stairwells, emergency exits, and equipment rooms.

Project Adaptability

● Suitable for large-scale developments requiring uniform design and safety compliance.


Manufacturing Excellence

Precision Production

● CNC cutting and forming ensure dimensional accuracy.

● Strict quality control guarantees consistent performance.

Material Selection

● Cold-rolled steel and treated wood panels ensure durability and resistance to deformation.


Maintenance Tips

1.Daily Care

● Clean surfaces with a dry or neutral cloth.

● Avoid harsh chemicals that may damage finishes.

2.Hardware Check

● Inspect hinges and seals regularly for optimal performance.
